Rated Current: 8A-16A (Adjustable)
Rated Voltaeg: 110V AC
Rated Power: 3.5KW
Waterproof Grade: IP55(Shell) & IP65(Charging Gun)
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: plug-and-play
Plug: GBT/TYPE1/TYPE2/TESLA
Cable: 5 Meters or Customisable Lengths
Packed Weight: 3.5KG
Without Screen
charging and discharging EV Charger
Rated Current: 16A-32A-50A (Adjustable)
Rated Voltaeg: 110V-220V/250V-380V AC
GBT & TYPE2 Rated Power: 7KW/11KW/22KW
Type1 Rated Power: 7.6KW/9.6KW/11.5KW
Waterproof Grade: IP55(Shell) & IP65(Charging Gun)
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: WIFI/APP/BLUETOOTH/RFID CARD
Plug: GBT/TYPE1/TYPE2
Cable: 5 Meters or Customisable Lengths
Packed Weight: 5.0KG
Without Screen
Rated Power: 30KW(95kg)/40KW(101kg)/60KW(110kg)/60KW(120kg)
Design Standard: GB/T18487-2023
Double Charge Gun
Single Gun Max Output Current: 250A
EV Charger Size: 800*1850*800mm(W*H*D)
Screen Size: 7 Inch Touch Screen
Networking method: Ethernet/4G
Rated Current: 8A-32A (Adjustable)
Rated Voltage: 110V-220V AC
Rated Power: 3.5KW-7KW
Ingress Protection Rating: IP65
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: plug-and-play
Plug: GBT/TYPE1/TYPE2/TESLA
Cable: 5 Meters or Customizable Lengths
Packed Weight: 3.0KG
With 1.8 Inch Screen
Rated Current: 8A-32A (Adjustable)
Rated Voltage: 110V-220V AC
Rated Power: 3.5KW-7KW
Ingress Protection: IP65
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: plug-and-play
Plug: GBT/TYPE1/TYPE2/TESLA
Cable: 5 Meters or Customizable Lengths
Packed Weight: 3.0KG
With 2.8 Inch Screen
Rated Current: 8A-32A (Adjustable)
Rated Voltage: 110V-220V AC
Rated Power: 3.5KW-7KW
Ingress Protection: IP65
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: plug-and-play
Plug: GBT/TYPE1/TYPE2/TESLA
Cable: 5 Meters or Customizable Lengths
Packed Weight: 3.0KG
Without Screen
Rated Current: 16A-32A-50A (Adjustable)
Rated Voltage: 110V-220V/250V-380V AC
GBT & TYPE2 Rated Power: 7KW/11KW/22KW
Type1 Rated Power: 7.6KW/9.6KW/11.5KW
Ingress Protection: IP65
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: WIFI/APP/BLUETOOTH/RFID CARD
Plug: GBT/TYPE1/TYPE2
Cable: 5 Meters or Customizable Lengths
Packed Weight: 5.0KG
With 4.3 Inch Screen
Rated Current: 16A-32A-50A (Adjustable)
Rated Voltage: 110V-220V/250V-380V AC
GBT & TYPE2 Rated Power: 7KW/11KW/22KW
Type1 Rated Power: 7.6KW/9.6KW/11.5KW
Ingress Protection: IP65
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: WIFI/APP/BLUETOOTH/RFID CARD
Plug: GBT/TYPE1/TYPE2
Cable: 5 Meters or Customizable Lengths
Packed Weight: 5.0KG
With 4.3 Inch Screen
Rated Current: 16A-32A-50A (Adjustable)
Rated Voltage: 110V-220V/250V-380V AC
GBT & TYPE2 Rated Power: 7KW/11KW/22KW
Type1 Rated Power: 7.6KW/9.6KW/11.5KW
Ingress Protection: IP65
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: WIFI/APP/BLUETOOTH/RFID CARD
Plug: GBT/TYPE1/TYPE2
Cable: 5 Meters or Customizable Lengths
Packed Weight: 5.0KG
Without Screen
Rated Current: 16A-32A-50A (Adjustable)
Rated Voltaeg: 110V-220V/250V-380V AC
GBT & TYPE2 Rated Power: 7KW/11KW/22KW
Type1 Rated Power: 7.6KW/9.6KW/11.5KW
Waterproof Grade: IP55(Shell) & IP65(Charging Gun)
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: WIFI/APP/BLUETOOTH/RFID CARD
Plug: GBT/TYPE1/TYPE2
Cable: 5 Meters or Customisable Lengths
Packed Weight: 5.0KG
Without Screen
Rated Current: 16A-32A-50A (Adjustable)
Rated Voltaeg: 110V-220V/250V-380V AC
GBT & TYPE2 Rated Power: 7KW/11KW/22KW
Type1 Rated Power: 7.6KW/9.6KW/11.5KW
Waterproof Grade: IP55(Shell) & IP65(Charging Gun)
Flame Retardant Grade: UL94 V0
Plug Life: ＞10000 times
Operating Temperature: -20℃~ ＋50℃
Operating Humidity: 5%~95%
Use Method: WIFI/APP/BLUETOOTH/RFID CARD
Plug: GBT/TYPE1/TYPE2
Cable: 5 Meters or Customisable Lengths
Packed Weight: 5.0KG
Double Charger Gun Without Screen
Could Both Charge for Two Vehicles
Rated Power: 30KW(95kg)/40KW(101kg)/60KW(110kg)/60KW(120kg)
Design Standard: GB/T18487-2023
Double Charge Gun
Single Gun Max Output Current: 250A
EV Charger Size: 800*1850*800mm(W*H*D)
Screen Size: 7 Inch Touch Screen
Networking method: Ethernet/4G
